Page 17
PIM-17
IMAGE II
© Metal Sales Manufacturing Corporation/ Subject to change without notice/ Effective Date 9/11
800.406.7387 (Corporate Office) • www.metalsales.us.com
e
ndwall
wiTh
Z-C
losUre
(r
egleT
) d
eTail
e
ndwall
wiTh
f
oam
-C
losUre
(C
oUnTer
) d
eTail
image ii
Fasteners (by others)
Tube Sealant
Double Bead Tape Sealant
Image II Panel
Moisture Barrier (by others)
Pitch Break
Reglet Flashing
#8-18 x
3
/
4
" Truss Head Woodscrew (4 per panel)
Tube Sealant
1
/
8
" x
3
/
16
" Pop-Rivet (3 per panel)
Z-Closure
Fasteners (by others)
Tube Sealant
Double Bead Tape Sealant
Image II Panel
Moisture Barrier (by others)
Pitch Break
Counter Flashing
1
/
8
" x
3
/
16
" Pop-Rivet (1'-0" o.c.)
Image II Outside Closure
Double Bead Tape Sealant
3:12 Slope
Minimum
3:12 Slope
Minimum
CAUTION
Additional screws
may be required for
high snow loading
and steep slopes.
CAUTION
Additional screws
may be required for
high snow loading
and steep slopes.
Note: Z-Closures must be field cut and bent to fit between panel
ribs (see Architectural Manual).
