Memmert ICH/ ICH L Climate chambers - Manual (Page 14)

14 D30381 | Date 10/2014
Construction and description
2.7 Technical data
Appliance size 110 260 750
Appliance width D* [mm] Appliance width D* [mm] 745 824 1224
Appliance height E* [mm] 1233 1552 1950
Appliance depth F* (without door handle) [mm] 634 734 834
Depth of door lock [mm] Depth of door lock [mm] 56
Chamber width A* [mm] 560 640 1040
Chamber height B* [mm] 480 800 1200
Chamber depth C* [mm] 400 500 600
Chamber volume [litres] 108 256 749
Weight including packaging [kg] 127 209 324
Power [W]
ICH 1350
ICH L 1450 1530
Current consumption [A]
230 V 50/60 Hz 5.9
230 V, 50/60 Hz with
light light
6.3 6.7
115 V 50/60 Hz 11.8
115 V, 50/60 Hz with
light light
12.6 13.3
max. number of sliding shelves 5 9 14
max. load per sliding shelf [kg] 30
max. load per appliance [kg] 150 200
Working temperature range
(°C)
with humidity +10 to +60 °C
without humidity -10 to +60 °C
with light 0 to +60 °C
Setting temperature range (°C) -10 to +60 °C
Adjustment precision (°C) 0.1
Adjustment range humidity (% rh) 10 to 80
Adjustment precision humidity (% rh) 1
Illumination (only ICH L)
Light intensity (Lux) approximately 6000
Standard illuminant D65 6,500 K
Spectral range 315 to 400 nm, 5 W/m2
