Bryant LEGACY 580J - Manual (Page 9)

9
Table 4 – SOUND PERFORMANCE TABLE
MODEL
SIZE
COOLING
STAGES
Outdoor Sound (dB)
A---Wtg.
AHRI
370
Rating
63 125 250 500 1000 2000 4000 8000
17 2 84.1 84 92.2 83.9 80.4 81.8 78.7 76.5 72.2 65.4
20 2 84.1 84 92.2 83.9 80.4 81.8 78.7 76.5 72.2 65.4
24 2 86.5 87 95.6 87.5 84.2 84.2 81.7 77.9 73.2 66.3
28 2 85.9 86 97.1 88.3 84.4 83.3 80.7 77.4 73.4 67.3
LEGEND
dB --- Decibel
NOTES:
1. Outdoor sound data is measure in accordance with
AHRI standard 270---2008.
2. Measurements are expressed in terms of sound power.
Do not compare these values to sound pressure values
because sound pressure depends on specific environ-
mental factors which normally do not match individual
applications. Sound power values are independent of
the environment and therefore more accurate.
3. A---weighted sound ratings filter out very high and very
low frequencies, to better approximate the response of
“average” human ear. A---weighted measurements for
Bryant units are taken in accordance with AHRI stand-
ard 270---2008.
Table 5 – MINIMUM -- MAXIMUM AIRFLOW RATINGS -- NATURAL GAS & PROPANE
MODEL
SIZE
HEAT
SIZE
COOLING AL HX HEATING SS HX HEATING
MINIMUM MAXIMUM MINIMUM MAXIMUM MINIMUM MAXIMUM
17
LOW
4500 7500
2960 8150 2960 8150
MED 3880 7750 3880 7750
HIGH 4620 8570 4620 8570
20
LOW
5250 9000
2960 10860 2960 10860
MED 3880 9300 3880 9300
HIGH 4620 10000 4620 10000
24
LOW
6000 10000
2960 10860 2960 10860
MED 3880 11630 3880 11630
HIGH 4620 10000 4620 10000
28
LOW
7500 12500
2960 16300 2960 16300
MED 3880 15500 3880 15500
HIGH 4620 15000 4620 15000
580J
