MODEL NUMBER NOMENCLATURE
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
5 8 0 J E 1 7 D 3 1 0 G 1 A 0 A A
__________ ______ ________ ______
Unit Type
580 = Gas Heat RTU
Model
J (PuronR Refrigerant)
Packaging
A = Standard
Voltage
E = 460---3---60
Factory Installed Options
P = 208/230---3---60 0A = None
T = 575---3---60
Outdoor Air Options
Cooling Tons A = None
17 = 15 Ton B = Temp econo w/ baro relief
20 = 17.5 Ton D = Temp econo w/ PE (cent)
24 = 20 Ton H = Enthalpy econo w/ baro relief
28 = 25 Ton J = Enthalpy econo w/ PE (cent)
P = Manual outdoor air damper
Refrig. System/Gas Heat Options Q = 2 Position damper
D = 2---Stage Compressor w/Aluminum gas heat
exchanger Indoor Fan Options
F = 2---Stage Compressor w/Stainless steel gas heat 1 = Standard static option, Vertical
exchanger 2 = Medium static option, Vertical
K = Two Stage Cooling with Aluminum gas heat exchanger 3 = High static option, Vertical
and Perfect Humidity. (only available on RTPF coil B = Medium Static High Eff Motor/Vertical Supply,
models) Return Air Flow
M = Two Stage Cooling with Sainless Steel gas heat C = High Static High Eff Motor/Vertical Supply
exchanger and Perfect Humidity. (only available on Return Air Flow
RTPF coil models)
5 = Standard Static option, Horizontal
Heat Level Input 6 = Medium Static option, Horizontal
220 = 220,000 7 = High Static option, Horizontal
310 = 310,000 F = Medium Static High Eff Motor/Horizontal Supply,
400 = 400,000 Return Air Flow
G = High Static High Eff Motor/Horizontal Supply,
Novation Coil Only (Outdoor---Indoor---Hail Guard) Return Air Flow
G = Al/Al --- Al/Cu
H = Al/Al --- Cu/Cu
J = Al/Al --- E---coat Al/Cu
K = E---coat Al/Al --- Al/Cu
L = E---coat Al/Al --- E---coat Al/Cu
T = Al/Al --- Al/Cu, Louvered Hail Guards
U = Al/Al --- Cu/Cu, Louvered Hail Guards
V = Al/Al --- E---coat Al/Cu, Louvered Hail Guards
W = E---coat Al/Al --- Al/Cu, Louvered Hail Guards
X = E---coat Al/Al --- E---coat Al/Cu, Louvered Hail Guards
Round Tube Plate Fin Coil Options (Outdoor---Indoor---Hail Guard)
A = Al/Cu --- Al/Cu
B = Precoat Al/Cu --- Al/Cu
C = E---coat Al/Cu --- Al/Cu
D = E---coat Al/Cu --- E---coat Al/Cu
E = Cu/Cu --- Al/Cu
F = Cu/Cu --- Cu/Cu
M = Al/Cu --- Al/Cu---Louvered Hail Guards
N = Precoat Al/Cu --- Al/Cu---Louvered Hail Guards
P = E---coat Al/Cu --- Al/Cu---Louvered Hail Guards
Q = E---coat Al/Cu --- E---coat Al/Cu---Louvered Hail Guards
R = Cu/Cu --- Al/Cu---Louvered Hail Guards
S = Cu/Cu --- Cu/Cu---Louvered Hail Guards
