Sequence of operation (cont.), 580j – Bryant LEGACY 580J User Manual
Page 50
50
SEQUENCE OF OPERATION (cont.)
COMP
COND COIL
PERFECT HUMIDITY COIL
EVAP COIL
INDOOR ENTERING
AIR
OUTDOOR AIR
METERING
DEVICE
CLOSED VALVE
OPEN VALVE
RH1.x
RH2.x
CV.x
a48-8173
C11152
Subcooling Mode (Reheat 1) -- Perfect Humidityt System (581J17--28)
COMP
COND COIL
PERFECT HUMIDITY COIL
EVAP COIL
INDOOR ENTERING
AIR
OUTDOOR AIR
METERING
DEVICE
CLOSED VALVE
OPEN VALVE
RH1.x
RH2.x
CV.x
a48-8174
C11153
Hot Gas Reheat Mode (Reheat2) -- Perfect Humidity System (581J17--28)
580J
