Bryant LEGACY 580J User Manual
Page 10
10
Table 6 – PHYSICAL DATA
(COOLING)
15 -- 25 TONS
Novation -- All Aluminum Coil Design
580J*17
580J*20
580J*24
580J*28
Refrigeration System
# Circuits / # Comp. / Type
2 / 2 / Scroll
2 / 2 / Scroll
2 / 2 / Scroll
2 / 2 / Scroll
R---410a charge A/B (lbs)
9.5/12.0
9.5/12.0
14.4/12.5
12.5/13.0
Metering device
Acutrol
Acutrol
Acutrol
Acutrol
High---press. Trip / Reset (psig)
630 / 505
630 / 505
630 / 505
630 / 505
Low---press. Trip / Reset (psig)
54 / 117
54 / 117
54 / 117
54 / 117
Compressor Capacity Staging (%)
50 / 100
50 / 100
50 / 100
50 / 100
Evap. Coil
Material
Cu / Al
Cu / Al
Cu / Al
Cu / Al
Tube Diameter
3/8---in
3/8---in
3/8---in
3/8---in
Rows / FPI
4 / 15
4 / 15
4 / 15
4 / 15
Total face area (ft2)
19.56
19.56
22.00
23.11
Condensate drain conn. size
3/4---in
3/4---in
3/4---in
3/4---in
Evap. fan and motor
VERTICAL
Sta
nd
ar
d
Sta
tic
Motor Qty / Drive type
1 / Belt
1 / Belt
1 / Belt
1 / Belt
Max BHP
2.2
3.3
4.9
4.9
RPM range
514---680
622---822
690---863
717---911
Motor frame size
56
56
56
56
Fan Qty / Type
2 / Centrifugal
2 / Centrifugal
2 / Centrifugal
2 / Centrifugal
Fan Diameter (in)
15 x 15
15 x 15
15 x 15
15 x 15
Me
di
um
Sta
tic
Motor Qty / Drive type
1 / Belt
1 / Belt
1 / Belt
1 / Belt
Max BHP
3.3
4.9
6.5
6.5
RPM range
679---863
713---879
835---1021
913---1116
Motor frame size
56
56
184T
184T
Fan Qty / Type
2 / Centrifugal
2 / Centrifugal
2 / Centrifugal
2 / Centrifugal
Fan Diameter (in)
15 x 15
15 x 15
15 x 15
15 x 15
Hi
gh
S
tat
ic
Motor Qty / Drive type
1 / Belt
1 / Belt
1 / Belt
1 / Belt
Max BHP
4.9
6.5
8.7
8.7
RPM range
826---1009
882---1078
941---1176
941---1176
Motor frame size
56
184T
213T
213T
Fan Qty / Type
2 / Centrifugal
2 / Centrifugal
2 / Centrifugal
2 / Centrifugal
Fan Diameter (in)
15 x 15
15 x 15
15 x 15
15 x 15
Me
di
um
Sta
tic
Hi
gh
E
ff*
Motor Qty / Drive type
n/a
n/a
1 / Belt
1 / Belt
Max BHP
n/a
n/a
6.5
6.5
RPM range
n/a
n/a
835---1021
913---1116
Motor frame size
n/a
n/a
184T
184T
Fan Qty / Type
n/a
n/a
2 / Centrifugal
2 / Centrifugal
Fan Diameter (in)
n/a
n/a
15 x 15
15 x 15
Hi
gh
S
tat
ic
Hi
gh
E
ff*
Motor Qty / Drive type
n/a
1 / Belt
1 / Belt
1 / Belt
Max BHP
n/a
6.5
8.7
8.7
RPM range
n/a
882---1078
941---1176
941---1176
Motor frame size
n/a
184T
213T
213T
Fan Qty / Type
n/a
2 / Centrifugal
2 / Centrifugal
2 / Centrifugal
Fan Diameter (in)
n/a
15 x 15
15 x 15
15 x 15
*
Section 313 of the Energy Independence and Security Act of 2007 (EISA 2007) mandates that the efficiency of general purpose motors we use in our Light
Commercial Rooftops rated at 5.0 HP and larger be increased on or after December 19, 2010. We will offer both high and standard efficient motors until
inventory is depleted and then shift over solely to the high efficient motors only.
