Software implementation and parameter setting
Inputs and outputs menu
Application Box: digital inputs
5

54 HB 13.0001-EN 3.0
5.7.3 Application Box: digital inputs

Stop!
The application box, which can be purchased as part of the accessories from
Lenze, can only be evaluated if the 931M/W inverter is equipped with a ”local
CAN interface”.
For applications requiring agreater number of digital IOs or other functions(e.g. analogIOs
or a master frequency coupling), the servo inverters with the local CAN interface offer the
possibility of extending the functions via external function modules.
Currently 2 different designs of function modules or application boxes are available for
evaluating a greater number of digital IOs. Further function modules - e.g. for evaluating
analog signals or for a master frequency coupling - are under way. Further information on
this can be received from your Lenze sales department.
The ”Fluxx” operating program is optimised for the evaluation of the existing function
modules. These function modules are provided with a number of inputs and outputs
featuring clearly predefined functions as well as a freely configurable input and output,
respectively. All inputs and outputs can be configured as ”Active high” or ”Active low”. The
function modules feature the following technical data:
930FC140400 930FC030200
Type of protection IP 20 IP54
Digital inputs 14 3
Digital outputs 4 2
Predefined functions of the inputs z Start
z Stop
z
Limit switch, left
z Limit switch, right
z Quick stop
z
8 BCD-coded inputs for selecting the
100 travel data sets
z Limit switch, left
z Limit switch, right
User-definable inputs: 1 1
Predefined functions of the outputs z Fault
z
Edited data set
z Target reached
z Fault
User-definable outputs 1 1
Tab. 4 Technical data of the function modules
