Software implementation and parameter setting
Inputs and outputs menu
5

48 HB 13.0001-EN 3.0
5.7 Inputs and outputs menu
The 930 fluxxtorque servo drive can either be procured as a drive with a digital input and
output, respectively, or with a local CAN interface. Because of the local CAN interface, the
use of function modules is possible. Currently, diverse function modules with different
degrees of protection are provided, by means of which the evaluation of several inputs and
outputs is possible. Further function modules - e.g. for evaluting analog signals or for
effecting a master frequency coupling - are projected. More detailed information can be
gathered from your Lenze sales department.
fåéìíëLçìíéìíë
In the ”Inputs/outputs” tab, both variants of the 930 fluxxtorque servo drive (with digital
inputs/outputs or with a function module/application box) can be parameterised. In the
following, the settings required for this are described.
