Technical data 4
l
50 EDBMZ9374X DE/EN/FR 4.2
4 Technical data
General data
Field Values
Electrical connection Power supply +18 ... +30 VDC
Current consumption 80 mA at +24 VDC
Digital outputs Features l No electrical isolation
l Protected against short−circuits
Current per output max. 1 A
HIGH level +13 ... +30 VDC
LOW level 0 ... +5 VDC
Digital inputs Features No electrical isolation
Input resistance 3 k W ... 4 k W
HIGH level +13 ... +30 VDC
LOW level 0 ... +5 VDC
System bus (CAN) Protocol with reference to CANopen
(matched with the Lenze automation
components)
Communication medium DIN ISO 11898
Network topology Line
(terminated at both ends with 120
W)
System bus device Slave
max. number of devices 63
Baud rate [kBit/s] 20 50 125 250 500 1000
max. bus length [m] 2500 1000 500 250 80 25
Weight 110 g
Operating conditions
Ambient conditions
Climatic
Storage IEC/EN 60721−3−1 1K3 (−25 ... +70 °C)
Transport IEC/EN 60721−3−2 2K3 (−25 ... +70 °C)
Operation IEC/EN 60721−3−3 3K3 (0 ... +55 °C)
Permissible moisture Humidity class F without condensation (medium relative humidity
85 %)
Enclosure IP20
Maintenance Free of maintenance
