Function block library LenzeElectricalShaft.lib
Preface and general information
1−1
l
LenzeElectricalShaft.lib EN 1.2
1 Preface and general information
1.1 About this Manual
This Manual contains information on the function blocks that are included in the function block library
LenzeElectricalShaft.lib for the Drive PLC Developer Studio .
·
These function blocks can be used, for instance, in the 9300 Servo PLC automation system.
·
The function blocks are based on the functions that are available in the 9300 servo controller
(V2.0).
In Drive PLC Developer Studio (DDS) you make the basic settings for your drive application offline,
by using variables (in accordance with the IEC 61131−3 standard) as aids for parameterizing the
appropriate function blocks.
By using Global Drive Control (GDC) or keypad you can then Online set the parameters for the
required functionality of your drive application, by accessing the code positions for the various
instances of the function blocks.
1.1.1 Conventions in this Manual
This Manual uses the following conventions to distinguish between different types of information:
Variable names
are shown in the explanatory texts in italics:
·
The signal at nIn_a ..."
can be recognized by the names. They always begin with L_":
·
The FB L_ARIT can ..."
Instances
For function blocks that have one or more first instances, there are tables that describe the
corresponding codes:
Variable name L_ARIT1 L_ARIT2 Setting range Lenze
byFunction C0338 C0600 0 ... 5 1
You can access these codes Online is linked to Global Drive Control (GDC) or keypad .
Tip!
You can use the Parameter Manager to assign the same codes to these instances that are assigned
in the 9300 servo controller( V2.0).
1.1.2 Pictograms in this Manual
Use of
Pictographs Signal words
Warning of
material damage Stop! Warns of potential damage to material .
Possible consequences if disregarded:
Damage of the controller/drive system or its environment
.
Other notes Tip! This note designates general, useful notes.
If you observe it, handling of the controller/drive system is made easier.
