Commissioning
Addressing
5
EDKMF2133 DE/EN/FR 6.1 63
l
H2 Adressierung−SetSlaveAdress
Address settings through keypad or PC
Addresses are set using code C0009 (see controller code table)
DIP switches S1 − S7 must be in OFF position (= delivery state).
Address settings through the master class 2
With this method only one device must be connected to the bus. This can be achieved by a
special switch−on sequence.
Settings made through the master (master class 2) have an effect on the setting in code
C0009.
PROFIBUS station address Mapping to code C0009 (LECOM node address)
1−2 No (master addresses)
3−99 Yes (3−99)
100−125 Yes (C0009=2)
126 (LENZE setting) Yes (C0009=1)
Tab. 1 Assignment of station addresses to controllers
)
Note!
In the "Power On" status, the class 2 master can set a device address via the
"Set_Slave_Address" telegram.
