Electrical installation
Plug connectors
Feedback system
l
36
BA 33.0005−EN 2.0
6.3.3
Feedback system
Resolver
Terminal
Designation
Meaning
B1
B2
+ Ref
− Ref
Transformer windings
(reference windings)
B3
Not assigned
B4
B5
+ Cos
− Cos
Stator winding cosine
B6
B7
+ Sin
− Sin
Stator winding sine
B8
Not assigned
Incremental encoder / sin/cos absolute value encoder with Hiperface
Terminal
Designation
Meaning
B1
B2
+ U
B
GND
Supply +
Mass
B3
B4
A
A
Track A / + COS
Track A inverse / − COS
B5
B6
B
B
Track B / + SIN
Track B inverse / − SIN
B7
B8
Z
Z
Zero track / + RS485
Zero track inverse / − RS485
B10
1)
Shield − housing
Shield − incremental encoder
1)
The terminal is not assigned if insulation at N−end shield of the motor has been selected!
6.4
Plug connectors
(
Stop!
ƒ
Tighten the coupling ring of the connector.
ƒ
If plugs without SpeedTec bayonet nut connectors are used, the connector
boxes for the power / encoder / fan connections must be secured by O−rings
if loadings by vibration occur:
– M17 connector box with O−ring 15 x 1.3 mm
– M23 connector box with O−ring 18 x 1.5 mm
Plug−in connectors (plug/connector box) with SpeedTec bayonet nut
connectors are vibration−proof.
ƒ
If SpeedTec bayonet nut connectors are used, O−rings must be removed (if
any)!
ƒ
Never disconnect plugs when voltage is being applied! Otherwise, the plugs
could be destroyed! Inhibit the controller before disconnecting the plugs!
