Lenze E84AZESR Mains filter-RFI filter 42-96A - Manual (Page 50)

Electrical installation
Mounting steps
6
l
50 EDK84AZESxx DE/EN/FR/ES/IT 4.0
6.3 Mounting steps
How to connect the filter:
1. Connect the filter output cable to the X100 terminal strip at the standard
device.
2. Connect the mains cable to the mains terminal of the filter.
3. Attach the PE conductor on the supply side to the PE conductor screw.
– The PE connection must comply with EN 61800−5−1.
