Technical data
Rated data
4
l
39 EDK84AZESxx DE/EN/FR/ES/IT 4.0
4.2 Rated data
Basis of the data
Voltage Voltage range Frequency range
Mains V LN [V] V LN [V] f [Hz]
1/PE AC 230 180 − 0 % ... 264 + 0 % 45 ... 65
3/PE AC 400/500 320 − 0 % ... 550 + 0 % 45 ... 65
Voltage Frequency Current Number of
phases
 max.
+45 °C
 max.
+55 °C
Type [V] [Hz] [A] [A]
E84AZESR1834LD 400 50/60 50.4 37.8 3
E84AZESM2234LD 400 50/60 42.0 31.5 3
E84AZESM2234LDN001 400 50/60 50.8 38.1 3
E84AZESM3034LD 400 50/60 55.0 41.3 3
E84AZESM3734LD 400 50/60 68.0 51.0 3
E84AZESM4534LD 400 50/60 80.0 60.0 3
E84AZESM4534LDN001 400 50/60 96.0 72.0 3
 Temperature in the control cabinet
Power loss Inductance Voltage drop
Type P
V
[W] L [mH] DU [V]
E84AZESR1834LD 32 − −
E84AZESM2234LD 57 0.7 9.2
E84AZESM2234LDN001 80 0.58 9.3
E84AZESM3034LD 85 0.58 10.0
E84AZESM3734LD 89 0.35 7.5
E84AZESM4534LD 100 0.3 7.5
E84AZESM4534LD001 125 0.3 9.1
