Leica MC120 HD / MC170 HD User Manual Application 34
Additional Use of an HD Monitor (PC Mode)
General Notes
In PC mode, the microscope image is
always shown in the preview window of
Leica Application Suite. In addition, another HD
monitor can be connected via the HDMI inter-
face.
The resolution on the connected HD
monitor is limited by the live image
resolution of the LAS software. Due to techni-
cal limitations, it is not possible to display a Full
HD live image on the connected HD monitor. In
order to do this, you have to switch the Leica
MC120 HD / MC170 HD to HD mode (stand-
alone) (see page 18).
Connecting the HD monitor
1 Connect the Leica MC120 HD / MC170 HD
to the HD monitor using the HDMI cable.
1
1
PC-HD
HDMI
ON-OF F
