Leica MC120 HD / MC170 HD User Manual Instrument Setup 25
Checking the battery
1. Switch on the camera and HD monitor so that
you see the live image on the HD monitor.
2. Hold the remote control in the beam path
so that it faces upwards and press any key.
Because the camera's chip also responds to the
infrared range, you can see how the LED on top
of the remote control lights up on the HD moni-
tor. If this is not the case, the battery needs to
be changed.
Changing the Battery
1. Remove the battery cover on the rear side
of the remote control.
2. Replace the battery and close the battery
cover.
For the replacement, you need a button
battery of type CR2025.
You can insert a small piece of foam or a
folded piece of paper under the battery
cover to ensure better or more reliable battery
contact.
WB
OK
RC 2
2
Remote Control (continued)
1
2
