Leica MC120 HD / MC170 HD User Manual Application 28
Switching on the Leica MC120 HD / MC170 HD (Standalone)
Ensure that the optional objective is
screwed onto the microscope, the mode
switch is set to "HD" and the HD monitor is
switched on.
1. Set the on/off switch to "ON" to switch on
the Leica MC120 HD / MC170 HD.
2. The status light's LED switches from red to
green, a signal tone sounds and the live
image is displayed on the HD monitor - the
Leica MC120 HD / MC170 HD is ready to use.
PC-HD
HDMI
ON-OFF
If the Leica MC120 HD / MC170 HD is
connected to a computer in HD mode
(standalone):
