Leica Biosystems IPC User Manual
Page 59
57
Leica IP C
• Push a (new) cleaning cartridge as far as it
will go into the slot (
Fig. 62
).
• Unscrew the red cap (85) one turn and slide
the cartridge fully home.
• Push the security latch (86, in
Fig. 61
) back in
front of the cartridge.
+
Instructions for storage
(continued)
Fig. 63
72
69
Fig. 62
• Push the small lever (69,
Fig. 63)
upwards
under the print head.
64
85
• Open the hood of the printer
(4 in
Fig. 36
), then press the
CLEAN and LOADED keys simul-
taneously.
• The print head (72) moves up-
ward to a position approx. 1 cm
(� inch) away from the sealing
lip (
Fig. 63
).
• The "Ink Empty" LED will go out and "88" will
appear on the display.
• Press CLEAN to rinse the print head; "00" will
appear on the display. The display will go out
when the cleaning process is complete.
6. Cleaning and Maintenance
р
р
The cleaning process with solvent
takes approx. 3.5 minutes.
