Landoll SCPH-33 Subsoil Chisel Plow - Manual (Page 15)

1001 7K299
- 1J480 Shank Assembly, [26 1/2” shanks - SCP models ] (Items 1-8) 2 3 79.0
- 4K735 Shank Assembly, [32 1/2” shanks - SCPH models ] (Items 2-9) 2 3 81.6
1 1J479 26 1/2” Shank only, SCP-23 & SCP-33 2 3 69.0
2 1J484 Clamp 2 3 .5
3 1J485 Wearstrip 2 3 3.4
4 1J481 Point 2 3 6.0
5 1J486 Capscrew, 1/2-13 NC x 2 1/4” Long Gr. 5 2 3 .2
6 1C120 Flat Washer, 1/2” 4 6 -
7 5C392 Lock Nut, 1/2-13 NC 2 3 -
8 1C659 Roll Pin, 1/4” x 1 1/2” Long 2 3 -
9 4K656 32 1/2” Shank only, SCPH-23 & SCPH-33 2 3 71.6
10 6K995 L. H. Angle 2 3 30.5
11 6K996 R. H Angle 2 3 30.5
12 3J450 U-Bolt, 3/4” x 5 3/4” deep 8 12 1.86
13 1C211 Lock Washer, 3/4” 16 24 -
14 1C210 Hex Nut, 3/4-10 NC 16 24 .1
15 6D758 Bolt, 3/4-10 NC x 3 1/2” Long 2 2 .5
16 6C729 Lock Nut, 3/4-10 NC 2 2 .1
17 8D423 Bolt, 5/8-11 NC x 3 3/4” Long 2 3 .8
18 5C461 Lock Nut, 5/8-11 NC 2 3 .1
Page 13
Index Part No. Req’d
No. No. Description Weight
SHANK ASSEMBLY
Model
-23 -33
