Landoll SMT-6 Seedbed Mulch Tucker - Manual (Page 15)

PULVERIZER ASSEMBLY
Index Part No. Used
No. No. Description 8’ / 6’ Weight
1 6K982 Frame Weldment - 8' 1 119
9J841 Frame Weldment - 6’ 1 96
2 2K544 Tube 2 24.9
3 2K545 Angle 8 6.8
4 9D989 U-Bolt, 5/8-11 NC x 4 11/16 Ctrs. x 5 5/8” Deep 8 1.4
5 1B166 Lockwasher, 5/8” 16 -
6 1C392 Nut, 5/8-11 NC 16 -
7 6D301 Machine Bolt, 5/8-11 NC x 6 1/2” gr 5 8
8 5C461 Stover Nut, 5/8-11 NC 8 .07
9 1C334 Capscrew, 1/2 x 11/4” gr. 5 2 .1
10 1C109 Lockwasher, 1/2" 4 -
11 9D864 Drilled Bolt, 5/8 x 3-1/2" 4 .4
12 4D529 Slotted Nut, 5/8" 2 .1
13 2C864 Cotter Pin, 1/8 x 1" 2 -
2K994 Mounting Plate Assembly (Items 5 & 11-15) 2 5.8
14 2K546 Mounting Plate Weldment 2 4.4
15 9D669 Axle Mount (Cast Iron) 2 .9
16 9C016 Bearing (Square Bore) 2 1.7
17 5J375 Clamp Assembly - Complete (items 10 & 18-21) 2 4.5
18 9C031 Axle Clamp (Cast Iron) 2 3.7
19 9D673 U-Bolt, 1/2" 2 .7
20 1C390 Nut, 1/2" 4 .04
21 2D535 Set Screw, 1/2" 4 -
22 8C988 Wheel, 16" Notched (PPM Models) 24 / 18 31
23 9J874 Axle Assembly - 8' incl. Bearings 1 87
9J875 Axle Assembly - 6’ incl. Bearings 1 69
24 9C014 Bearing Housing (Casting Only) 2 7
25 2J430 Reflective Decal - Red 2 -
26 4K036 Decal, “Brillion” 2 -
Page 13
200rev502 6K600
