COULTER ASSEMBLY [SMT8 Models -from February 2001]
Index Part
No. No. Description No. Used Weight
1 6K982 Frame Weldment - 8' 1 119
9J841 Frame Weldment - 6’ 1 96
2 6K983 Hitch Bracket 2 18.5
3 7K227 Sleeve - 1 1/8 OD x 29/32” ID x 1 13/32” Long 4 .14
4 7K226 Sleeve - 1 7/16” OD x 1 1/8” ID x 1 13/32” Long 4 .23
5 6k977 Mast 1 15
6 9D989 U-Bolt, 5/8" 2 1.4
7 1B166 Lockwasher, 5/8" 4 -
8 1C392 Nut, 5/8" 4 -
9 3J910 Clevis Pin, 7/8” x 3 1/2” 2 .6
10 5D110 Klik-Pin 2 .1
11a 2J431 Decal, Reflective Amber 2 -
11b 2J430 Decal, Reflective Red 2 -
6K975 Coulter Assembly -8’ (Shown) [Items 12-26] 1 334
6K622 Coulter Assembly -6’ 1 260
12 2K539 Square Shaft, 8’ 1 66.22
6K623 Square Shaft, 6’ 1 50.9
13 2K540 20” Notched Coulter 12 14.58
14 2K541 Spacer, 4.914” 2 3.13
15 2K542 Spacer, 7 13/16” 10 4.98
16 2K543 Plate 3 4.31
17 9J559 Carriage Bolt 12 .12
18 1C109 Lockwasher 12 -
19 1C390 Nut 12 .04
20 8C527 Capscrew, 1/2-13 NC x 1 1/2” gr. 5 6 .1
21 3J131 Bearing 3 3.0
22 3K045 Bearing Flange 6
23 7D795 Washer 2 -
24 2J716 Slotted Nut 2 .1
25 6D049 Cotter Pin 2 -
26 6K976 Spacer, 3 1/4” Long 2 2
27 8C527 Capscrew, 1/2-13 NC x 11/2” gr. 5 4 .1
28 2D488 Capscrew, 3/4-10 NC x 5” 2
29 6C729 Locknut, 3/4” 2
30 6K973 Center Bracket 1 11.2
31 7K107 Float Link 1 5\
32 4K036 Decal, “Brillion” 1 -
33 6D355 Capscrew, 5/8-11 NC x 6” gr. 5 4 .56
34 9J850 Stand Weldment 1 5.8
35 9J851 Screw 1 .1
36 9J845 Bracket 1 2.2
37 5C077 Clevis Pin, 3/4” 1 .13
38 6J448 Hairpin Cotter 1
39 6K984 Sleeve, 2” OD x 1 1/8” ID x 1 13/32” Long
Page 9
200rev8-10-06 6K600
