1/2” x 6" hydraulic cylinder, Ge 2-55) – Landoll 4630-36 Folding Seeder Parts Manual v.F-641-1213 12/2013 User Manual
Page 61
ILLUSTRATED PARTS LIST
2-55
3-1/2” X 6" Hydraulic Cylinder
ITEM
PART NO.
DESCRIPTION
QTY.
167310
CYLINDER, HYDRAULIC 3-1/2” X 6"
1
142803
PISTON ROD
1
2
-----
BUTT AND TUBE ASSEMBLY
1
3
-----
PISTON
1
4
142806
GLAND
1
5
-----
LOCKNUT
1
6
-----
PORT PLUG
2
7
-----
O-RING
1
8
-----
CROWN SEAL
1
9
-----
O-RING
1
10
-----
BU-WASHER
1
11
-----
U-CUP
1
12
-----
CANNED WIPER
1
142807
PACKING KIT (INCL ITEMS 7-12)
