Main hitch frame assembly – Landoll 4630-36 Folding Seeder Parts Manual v.F-641-1213 12/2013 User Manual
Page 12
2-6
F-641-1213 Edition
ILLUSTRATED PARTS LIST
Main Hitch Frame Assembly
ITEM
PART NO.
DESCRIPTION
QTY.
1
1-242-010172-3
CYLINDER, HYDRAULIC 4 X 24 (SEE PAGE 2-47)
1
2
1-511-010001-05
NUT, HEX JAM 1/2-13
4
3
1-512-010005-01
NUT, HEX LOCK 1/4-20 GRB
4
4
1-512-010005-05
NUT, HEX LOCK 3/8-16 GRB
2
5
1-512-010005-09
NUT, HEX LOCK 1/2-13 GRB
13
6
1-512-010005-13
NUT, HEX LOCK 5/8-11 GRB
1
7
1-512-010005-15
NUT, HEX LOCK 3/4-10 GRB
10
8
1-512-010005-19
NUT, HEX LOCK 1-8 GRB
3
9
1-647-010004240
PIN, SPRING SLOTTED 5/16 X 2-1/2
2
10
1-654-010047-10
SCREW, HEX HEAD CAP 1/4-20 X 2 GR5
4
11
1-654-010051-13
SCREW, HEX HEAD CAP 3/8-16 X 3 GR5
2
12
1-654-010055-01
SCREW, HEX HEAD CAP 1/2-13 X 1 GR5
32
13
1-654-010055-03
SCREW, HEX HEAD CAP 1/2-13 X 1-1/2 GR5
2
14
1-654-010055-05
SCREW, HEX HEAD CAP 1/2-13 X 2 GR5
7
15
1-654-010055-09
SCREW, HEX HEAD CAP 1/2-13 X 3 GR5
1
16
1-654-010055-14
SCREW, HEX HEAD CAP 1/2-13 X 4-1/2 GR5
4
17
1-654-010059-09
SCREW, HEX HEAD CAP 5/8-11 X 3 GR5
1
18
1-654-010061-05
SCREW, HEX HEAD CAP 3/4-10 X 2 GR5
10
19
1-861-010032-11
WASHER, FLAT 3/8W
2
20
1-861-010032-24
WASHER, FLAT 1"N
2
21
1-861-010034-13
WASHER, SPLIT LOCK 1/2
32
22
114616
SCREW, HEX HEAD CAP 1-8 X 8-1/2 GR5
1
23
140519
BEARING, UHMW 4"
3
24
141434
SAFETY CHAIN, 21,000 LB
1
161536
HOOK, SAFETY CHAIN 21,000 LB
1
25
143916
PLATE, SLIDE
8
26
144003
HUB AND SPINDLE ASSEMBLY, 8 BOLT (SEE PAGE 2-9)
4
27
144113
SPRING, COMPRESSION 8"
*1,2
28
144138
VALVE, STOP
1
29
144355
PIN, 1 X 8
1
30
144356
PIN, 1-1/2 X 4-5/8
2
31
151533
SHIM, HITCH SLIDE
8
32
153696
BOLT, HITCH CLEVIS 1-8 X 7-1/2
2
33
153827
SHIM, LIFT BEARING
6
34
153859
PIN 1-1/2 X 10
1
35
167272
HITCH, SEEDER 36’
1
36
167299
TIRE AND WHEEL ASSEMBLY 12.5 X 15 FI (INCL ITEMS 37-39)
4
37
167298
WHEEL, 15 X 10 LB 8 BOLT 3/8
1
38
2-798-010106
TIRE 12.5L X 15
1
39
TR416
VALVE STEM, TUBELESS TIRE
1
40
167310
CYLINDER, HYDRAULIC 3-1/2 X 6 (SEE PAGE 2-55)
1
41
167311
LIFT WELDMENT, CENTER
1
42
167314
CAP BEARING WELDMENT, LIFT
3
43
167315
LINK WELDMENT, TRANSPORT LOCK
2
44
167316
ROD WELDMENT, TRANSPORT LOCK
1
45
167317
BRACKET, TRANSPORT LOCK
1
46
167318
MOUNT, RELEASE VALVE
1
47
167319
COUPLER WELDMENT, TRANSPORT LOCK
1
48
167320
SLEEVE, TRANSPORT LOCK
1
