Page 9: Specifications -3

TM
Model 3500
M0240-01
6/11
1-3
Specification
Number of Rows
6 Row 30"
8 Row 30"
Weight Empty (Mechanical)*
5,187 lbs (2352.8 kg)
5,886 lbs (2669.8 kg)
Weight Empty (EdgeVac)*
5,443 lbs (2468.9 kg)
6,269 lbs (2843.6 kg)
Transport Height
10' 6" (3.2M)
10' 6" (3.2M)
Planting Length
19' 8" (6.0M)
19' 8" (6.0M)
Transport Length
23' 9" (7.3M)
26' 5" (8.4M)
Planting Width
16' 10" (5.2M)
21' 10" (6.7M)
Transport Width
11' 2" (3.5M)
11' 2" (3.5M)
Seed Capacity
1.75 bu. (EdgeVac / Hopper); 1.90 bu. (Mechanical / Hopper)
Transport Tires
Four 7.50" x 20" 8 ply rib implement tires w/ center groove - Inflate to 40 psi (275.7 kPa)
Contact Drive Tires
Two 4.10" x 6" spring-loaded contact drive tires. - Inflate to 50 psi (344.7 kPa)
Field Lift
One center post lift cylinder. (Front or rear mount.)
Row Markers
Two-fold low profile with 16" concave, solid blades and cast iron hubs.
*Base machine weights include planter frame including row markers, hydraulic cylinders, hoses, fittings, tires, wheels,
drive and drill shafts, sprockets, chains and required drive components, parking jack, safety/warning lights, SMV sign,
transport safety chain, and Kinze pull row units (closing wheel arms less closing wheels) with seed hopper, lid, and dual
quick adjustable down force springs option. EdgeVac includes additional weight of fan, manifolds, and hoses.
Tractor Hydraulic Requirements
Configuration
Requirements
Description
Base machine with mechanical meters.
2 SCV
10 gpm
#1 SCV: Planter lift
#2 SCV: Markers/fold (manual selector valve)
Base machine with EdgeVac meters.*
3 SCV
25 gpm
#1 SCV: Planter lift
#2 SCV: Markers/fold (manual selector valve)
#3 SCV: EdgeVac fan
Base machine with EdgeVac meters
and tractor mounted PTO pump.*
2 SCV
15 gpm
#1 SCV: Planter lift
#2 SCV: Markers/fold (manual selector valve)
*Seed meter/vacuum system
- 13 GPM @ 2000- Zero PSI Case Drain Plus One SCV (Pressure And Return) for
Vacuum Fan Hydraulic Motor.
Specifications
