Page 87
TM
Model 3500
M0240-01
Rev. 8/11
5-17
Rate Charts
PLANTING RATES FOR (EDGEVAC) ACID-DELINTED HILL-DROP COTTON (3 SEEDS PER CELL) 20 CELL DISCS
19 TOOTH CONTACT WHEEL DRIVE/23 TOOTH REVERSER DRIVEN SPROCKETS (SEE PAGE 5-1)
APPROxIMATE SEEDS/ACRE FOR VARIOUS ROW WIDTHS
15" Rows
30" Rows
Transmission Sprockets
Drive Driven
Recomm. Speed
(MPH)
Average Spacing
In Inches
30,149
15,074
15
28
4 to 6
13.9
31,266
15,633
15
27
4 to 6
13.4
32,468
16,234
15
26
4 to 6
12.9
33,767
16,883
15
25
4 to 6
12.4
34,169
17,084
17
28
4 to 6
12.2
35,174
17,587
15
24
4 to 6
11.9
35,434
17,717
17
27
4 to 6
11.8
36,703
18,352
15
23
4 to 6
11.4
36,797
18,399
17
26
4 to 6
11.4
38,189
19,094
19
28
4 to 6
11.0
38,269
19,135
17
25
4 to 6
10.9
39,603
19,802
19
27
4 to 6
10.6
39,864
19,932
17
24
4 to 6
10.5
41,126
20,563
19
26
4 to 6
10.2
41,597
20,798
17
23
4 to 6
10.1
42,771
21,386
19
25
4 to 6
9.8
44,430
22,215
15
19
4 to 6
9.4
44,554
22,277
19
24
4 to 6
9.4
46,228
23,114
23
28
4 to 6
9.0
46,491
23,245
19
23
4 to 6
9.0
47,941
23,970
23
27
4 to 6
8.7
48,238
24,119
24
28
4 to 6
8.7
49,657
24,829
15
17
4 to 6
8.4
49,784
24,892
23
26
4 to 6
8.4
50,025
25,012
24
27
4 to 6
8.4
50,248
25,124
25
28
4 to 6
8.3
50,354
25,177
17
19
4 to 6
8.3
51,776
25,888
23
25
4 to 6
8.1
51,949
25,975
24
26
4 to 6
8.0
52,109
26,055
25
27
4 to 6
8.0
52,258
26,129
26
28
4 to 6
8.0
53,933
26,967
23
24
4 to 6
7.8
54,027
27,013
24
25
4 to 6
7.7
54,114
27,057
25
26
4 to 6
7.7
54,194
27,097
26
27
4 to 6
7.7
54,268
27,134
27
28
4 to 6
7.7
56,278
28,139
23
23
4 to 6
7.4
58,362
29,181
28
27
4 to 6
7.2
58,443
29,221
27
26
4 to 6
7.2
58,623
29,312
25
24
4 to 6
7.1
58,725
29,362
24
23
4 to 6
7.1
60,607
30,304
28
26
4 to 6
6.9
60,780
30,390
27
25
4 to 6
6.9
61,172
30,586
25
23
4 to 6
6.8
62,899
31,450
19
17
4 to 6
6.6
63,031
31,516
28
25
4 to 6
6.6
63,313
31,656
27
24
4 to 6
6.6
63,619
31,809
26
23
4 to 6
6.6
65,658
32,829
28
24
4 to 6
6.4
66,066
33,033
27
23
4 to 6
6.3
68,126
34,063
23
19
4 to 6
6.1
68,512
34,256
28
23
4 to 6
6.1
71,088
35,544
24
19
4 to 6
5.9
74,050
37,025
25
19
4 to 6
5.6
76,141
38,070
23
17
4 to 6
5.5
NOTE: See “General Planting Rate Information” and “Check Seed Population” pages for more information.
Always field check seed population to verify planting rates.
