M0240-01 Model 3500
6-32 6/11
TM
Lubrication and Maintenance
ELECTRICAL WIRING DIAGRAM FOR LIGHT PACKAGE
Light package meets ASABE Standards. For correct wiring harness to be wired into lights on your tractor, check with
tractor manufacturer.
3-Pin Connector 3-Pin Connector
A
C
b
A
C
b
White MONITOR +12V
Green MONITOR DATA
black MONITOR GROUND
* Optional customer-supplied auxiliary lights and wires may be wired into existing plug terminals.
