KD Scientific Allegro Peristaltic Pump System User’s Manual
Publication 5613-004-REV-A
General Information
Specifications
Accuracy ± 0.5%
Tubing (Min./Max.) 0.8-8.0 mm (Allegro I, III); 0.8-4.8 mm (Allegro II)
Tubing Durometer Range (Min./Max.) 55A-62A
Flow Rate (per channel, tubing dependant)*
Display 4.3" WQVGA TFT Color Display with
Touch Screen
Non-Volatile Memory Stores all settings
Connectors:
RS-485 IEEE-1394, 6 pos
USB Type B
I/O & TTL 15 pin D-Sub Connector
Footswitch mini phone jack
Pressure (Max) 30 psi
Drive Motor 1.8° Stepper Motor
Motor Drive Control Microprocessor with 1/16 microstepping
Step Rate:
Minimum 27.5 sec/µstep
Maximum 26 µsec/µstep
Maximum RPM:
Allegro I 375
Allegro II/III 312
Input Power 30 VDC
Input Power Connection 2.5mm ID x 5.5mm OD male plug
Power Supply 100-240 VAC, 50-60 Hz, 8 Watts Universal
Power Supply, Use Only a KD Scientific
Approved Power Supply and Line Cord
Dimensions (Control Box) (W x D x H) 22.9 x 19.7 x 7.6 cm (9.0 x 7.75 x 3.0 in)
Dimensions (Pump Head) (W x D x H) 11.5 x 24.1 x 11.8 cm (4.5 x 9.5 x 4.63 in)
Weight 2.66 kg (5.9 lbs)
*Please see tubing table (Appendix A).
