55
Operating the KDS Legato 130
K
D
S
L
e
g
a
to
1
3
0
U
s
e
r’s
M
a
n
u
a
l
phone
508.429.6809
fax
508.893.0160
e-mail
[email protected]
web
www.kdscientific.com
KD Scientific Legato 130 Syringe Pump User’s Manual
Publication 5617-008 Rev D
IRATE
Sets or displays the infusion rate. Configuration Run
screen mode only. The rate argument may be replaced
by “max” or “min” to set the maximum or minimum rate,
respectively. “lim” may be used to display the range
limits.
Command format:
irate [max|min|lim|{rate} {rate units}]
Query response:
[##:]# xl/xxx
[##]
or:
[##:]# xl/xxx to # xl/xxx
[##]
WRAMP
Sets or displays the withdraw rates while ramping.
Configuration Run screen mode only.
Command format:
wramp [{start rate} {end rate} {rate units}
{ramp time in seconds}]
Query response:
[##:]Ramp not set up.
[##]
or:
[##:]# xl/xxx to xl/xxx in # seconds
[##]
WRATE
Sets or displays the withdraw rate. Configuration Run
screen mode only. The rate argument may be replaced
by “max” or “min” to set the maximum or minimum rate,
respectively. “lim” may be used to display the range
limits.
Command format:
wrate [max|min|lim|{rate} {rate units}]
Query response:
[##:]# xl/xxx
[##]
or:
[##:]# xl/xxx to # xl/xxx
[##]
Volume commands
CIVOLUME
Clears the infused volume. Configuration Run screen
mode only.
Command format:
civolume
CTVOLUME
Clears the target volume. Configuration Run screen mode
only.
Command format:
ctvolume
CVOLUME
Clears both the infused and withdrawn volumes.
Configuration Run screen mode only.
Command format:
cvolume
CWVOLUME
Clears the withdrawn volume. Configuration Run screen
mode only.
Command format:
cwvolume
IVOLUME
Displays the infused volume. Configuration Run screen
mode only.
Command format:
ivolume
Query response:
[##:]# xl
[##]
SVOLUME
Sets or displays syringe volume. Configuration Run screen
mode only.
Command format:
svolume
Query response:
[##:]#.####ul
[##]
or:
[##:]#.#### ml
[##]
✐
NOTE: For commands requiring rate units,
use the following format: m, u, n, p / h, m, s
Ex: m/m = milliliter / minute
Ex: n/s = nanoliter / second
✐
NOTE: To clear a ramp, use CTTIME
command.
