KD Scientific Legato 130 Series User Manual
Page 11
11
Product Over view
K
D
S
L
e
g
a
to
1
3
0
U
s
e
r’s
M
a
n
u
a
l
KD Scientific Legato 130 Syringe Pump User’s Manual
Publication 5617-008 Rev D
Easy external connections to a computer or other
control devices are made through USB and Digital
I/O. Simple ASCII commands make communication
with the pump easy. For direct control of the pump,
the user can use the I/O interface (15pin Dsub). A
trigger output and a trigger input in for external
events such as a process parameter is met. The
footswitch input will allow the control of the pump
through an external device. The unit also has an
output for run indication allowing connection to a
remote light.
The Legato 130 offers complete flexibility with the
user able to use most manufacturer’s syringes with
sizes ranging from 0.5 ul to 1 ml.
The infuse/withdraw programmable Legato 130
offers maximum flexibility and capability for
configuring and running different programs. Up to 2
programs of 50 steps each can be configured and
stored in the unit, and recalled quickly with the touch
of a button. The programs are identified with a 15
character alphanumeric name for easy identification
and can be stored on the computer and downloaded
at future dates. A relative clock is available to start
and stop programs based on time. Extensive
programming options allow the user to duplicate
configurations, append one configuration to another,
rename programs, delete programs, export programs
to a PC or export a program to another pump. This
feature can ensure consistency and accuracy of
multiple pumps.
Preprogrammed profiles include Constant Rate and
Ramp. These standard profiles make configuration easy
to set up. If more complexity is needed the user can select
from advanced programming options including:
•
Time delays
•
Repeating steps
•
Stopping the pump
•
Triggering the pumps TTL output
•
Accepting an event input in such as a user
touch or motor stall
•
Events can trigger the pump to withdraw or infuse
The pump Information/setup screen shows the pump’s
software version, and lubrication intervals. The pump’s
alarm configurability includes alarms for near end of run
(user selectable), completion of run, power up, and
keypad clicks.
Pump Model
Legato 130
– Single syringe infuse/withdraw with
program option for 2 programs, 50 steps each..
