Data Sheet 706030 JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 4/12
Electrical data
Housing
Approvals/marks of conformity
Print head print head with penlift function - sufficient for approx. 1 million dots
(depending on the ambient temperature)
Print colors Violet, red, black for 3-channel printing recorder and
violet, red, black, green, blue, brown for 6-channel printing recorder.
The color assignment can be changed at will, through the setup program.
Over/underrun electronically limited to 0 — 100mm writing width
Chart speed programmable in the steps 0, 5, 10, 20, 60, 120, 240, 300, 360, 600, 720mm/h
Paper feed by stepper motor and gearing
Chart cassette cassette for roll chart and fanfold chart (with tear-off edge and paper-end switch)
Chart
overall width / writing width
sprocket roller spacing
visible diagram length
overall length
roll or fanfold chart to DIN 16320
120mm / 100mm
110mm
roll chart: 60mm; fanfold chart: 30 — 60mm
roll chart: 16m or 32m; fanfold chart: 15.6m
Supply (SMPS) 110 — 240V AC +10/-15% AC 48 — 63Hz, or 20 — 53V ±0% AC/DC 48 — 63Hz
Electrical safety
Test voltages (type test)
mains supply to measurement circuit
mains supply to housing
between measurement circuits
measurement circuits to housing
electrical isolation between the
analog inputs
to EN 61010, Part 1, March 1994
overvoltage Category II, contamination Grade 2
with AC supply 2.3kV 50Hz, 1min; with AC/DC 510V 50Hz, 1min
with AC supply 1.5kV 50Hz, 1min; with AC/DC 510V 50Hz, 1min
200V 50Hz, 1min
500V 50Hz, 1min
up to 30V AC and 50V DC
Supply voltage sensitivity less than 0.1% of range span
Power consumption 35VA max.
Data buffering More than 4 years through lithium battery in RAM or 2 days with storage capacitor at
5 — 25°C ambient temperature. Additional backup in EEPROM.
Electrical connection At rear through plug-in screw terminals,
max. conductor cross-section 2.5mm 2 or 2x 1.5mm 2 with core end sleeves.
Setup connector at the front behind flip-up dot-matrix display.
Electromagnetic compatibility (EMC)
interference emission
immunity to interference
EN 61326-1
Class B
to industrial requirements
Housing type
housing door
Housing for front-panel mounting to IEC 61554, galvanized sheet steel
cast zink
Transport mechanism in corrosion-resistant chrome-nickel steel
Chart cassette in plastic (polycarbonate)
Bezel size 144mm x 144mm
Depth behind panel 212mm without screw terminals; 227mm with screw terminals plugged in
Panel cut-out 138 +1.0 mm x 138 +1.0 mm
Housing mounting in control panel to DIN 43834
Ambient temperature range 0 to 50°C
Ambient temperature error 0.2%/10°C
Storage temperature range -20 to +70°C (without print head), -20 to +55 °C (with print head)
Climatic conditions 20 — 70% relative humidity, no condensation
Operating position normal position: vertical ± 30° (NL 90 ± 30, to DIN 16257)
Protection to EN 60529 Category 2,
front IP54 (IP65 with extra code 266),
rear IP20
Weight 3.5 kg max.
Mark of
conformity Testing
laboratory Certificates /
certification numbers Test basis valid for
c UL us Underwriters
Laboratories E 201387 UL 3111-1
CAN/CSA C22.2 No. 1010.1-92 the flush-mounted instrument;
not in conjunction with any hou-
sing extra code
