Data Sheet 706030 JUMO GmbH & Co. KG • 36035 Fulda, Germany Page 2/12
Technical data
Thermocouple input
Resistance thermometer input
Designation Range Linearisation accuracy
1
Fe-Con L DIN 43710
2
Fe-Con J EN 60584
Cu-Con U DIN 43710 2
Cu-Con T EN 60584
NiCr-Ni K EN 60584
NiCr-Con E EN 60584
NiCrSi-NiSi N EN 60584
Pt10Rh-Pt S EN 60584
Pt13Rh-Pt R EN 60584
Pt30Rh-Pt6Rh B EN 60584
-200 to + 900°C
-210 to +1200°C
-200 to + 600°C
-270 to + 400°C
-270 to +1372°C
-270 to +1000°C
-270 to +1300°C
-50 to +1768°C
-50 to +1768°C
0 — 1820°C
±0.2%
±0.2% above -200°C
±0.3%
±0.5% above -200°C
±0.2% above -150°C
±0.2% above -200°C
±0.2% above -150°C
±0.5% above 0°C
±0.5% above 0°C
±0.5% above 500°C
Shortest span Types L, J, U, T, K, E, N:
Types S, R, B: 100°C
500°C
Range start/end freely programmable within the limits in 0.1°C steps
Cold junction Pt 100 internal or thermostat as external constant
Cold junction accuracy (internal) ± 1°C
Cold junction temperature (external) -50 to +100°C, adjustable through setup software
Measurement time for 3 channels < 2sec; for 6 channels < 4sec
Input filter 2nd order digital filter; filter constant adjustable from 0 — 50.0sec
Features also programmable in °F; customer-specific linearizations
1 The linearization accuracy refers to the maximum span. The linearization accuracy is reduced for shorter spans.
2 invalid DIN since 1995
Connection Range Linearisation accuracy Meas.
current
Pt 100 EN 60751 2/3-wire
2/3-wire
4-wire
4-wire -200 to +250°C
-200 to +850°C
-200 to +250°C
-200 to +850°C ±0.6°C
±1.0°C
±0.5°C
±0.8°C 500
A
250
A
500
A
250
A
Pt 100 JIS 2/3-wire
2/3-wire
4-wire
4-wire -200 to +260°C
-200 to +649°C
-200 to +260°C
-200 to +649°C ±0.6°C
±1.0°C
±0.5°C
±0.8°C 500
A
250
A
500
A
250
A
Pt 500 DIN 2/3-wire
2/3-wire
4-wire
4-wire -200 to +150°C
-200 to +850°C
-200 to +150°C
-200 to +850°C ±0.6°C
±1.0°C
±0.5°C
±0.8°C 250
A
250
A
250
A
250
A
Pt 1000 DIN 2/3-wire
2/3-wire
4-wire
4-wire -200 to +250°C
-200 to +850°C
-200 to +250°C
-200 to +850°C ±0.6°C
±1.0°C
±0.5°C
±0.8°C 500
A
250
A
500
A
250
A
Ni 100 2/3-wire
2/3-wire
4-wire
4-wire -60 to +125°C
-60 to +180°C
-60 to +125°C
-60 to +180°C ±0.6°C
±1.0°C
±0.5°C
±0.8°C 500
A
250
A
500
A
250
A
Connection type 2-, 3- or 4-wire circuit
Shortest span 15°C
Probe lead resistance max. 30
 per core for 4-wire circuit
max. 20
 per core for 2- and 3-wire circuit
for Pt 100 up to 260°C max. 10
 per core in 2-wire and 3-wire circuit
Range start/end freely programmable within the limits in 0.1°C steps
Measurement time for 3 channels < 2sec; for 6 channels < 4sec
Input filter 2nd order digital filter; filter constant adjustable from 0 — 50sec
Features also programmable in °F; customer-specific linearizations
