Connection diagram
Rear view of a 3/ 6-channel paperless recorder with pluggable screw terminals
Terminal assignments for 3 /6-channel paperless recorder Diagram
Analog inputs Connector
Thermocouple 1 to 6
RTD in 2-wire circuit 1 to 6
RTD in 3-wire circuit 1 to 6
RTD in 4-wire circuit 1 to 6
Voltage input
≤
210mV 1 to 6
Voltage input > 210mV 1 to 6
Current input 1 to 6
PE N L1
(L-) (L+)
1 1 1
1 1 1
21.
33. 20. 32. 31. 30.
1 1 1 1
Cut-outs for cables ties with foot for strain r
elief
5. 4. 6.
2. 1. 3.
