Technical data
Analog inputs
Input for DC voltage, DC current
Thermocouple
Basic range Accuracy Input resistance
-20 to +70mV
-3 to +105mV
-10 to +210mV
-0.5 to +12V
-0.05 to +1.2V
-1.2 to +1.2V
-10 to +12V
±80
μ
V
±100
μ
V
±240
μ
V
±6mV
±1mV
±2mV
±12mV
R
IN
≥
1 M
Ω
R
IN
≥
1 M
Ω
R
IN
≥
1 M
Ω
R
IN
≥
470 k
Ω
R
IN
≥
470 k
Ω
R
IN
≥
470 k
Ω
R
IN
≥
470 k
Ω
Shortest span 5mV
Range start/end freely programmable within the limits in 0.01 mV steps
-2 to +22mA
-22 to +22mA
±20
μ
A
±44 μ A
burden voltage
≤
1V
burden voltage ≤ 1V
Shortest span 0.5mA
Range start/end freely programmable within the limits in 0.01 mA steps
Overrange / underrange according to NAMUR NE 43
Sampling cycle 3 or 6 channels 250msec
Input filter 2nd order digital filter; filter constant adjustable from 0 to 10.0sec
Test voltage for electrical isolation 350V (via optocoupler)
Resolution >14 bit
Designation Type Standard Meas. range Accuracy 1
Fe-Con L DIN 43 710
Fe-Con J EN 60 584
Cu-Con U DIN 43 710
Cu-Con T EN 60 584
NiCr-Ni K EN 60 584
NiCr-Con E EN 60 584
NiCrSi-NiSi N EN 60 584
Pt10Rh-Pt S EN 60 584
Pt13Rh-Pt R EN 60 584
Pt30Rh-Pt6Rh B EN 60 584
W3Re/W25Re D
W5Re/W26Re C
Chromel-Copel GOST R 8.585-2001
-200 to +900°C
-210 to +1200°C
-200 to +600°C
-270 to +400°C
-270 to +1372°C
-270 to +1000°C
-270 to +1300°C
-50 to +1768°C
-50 to +1768°C
0 to 1820°C
0 to 2400°C
0 to 2320°C
-200 to +800°C
±0.1%
±0.1% from -100°C
±0.1% from -150°C
±0.15% from -150°C
±0.1% from -80°C
±0.1% from -80°C
±0.1% from -80°C
±0.15% from 0°C
±0.15% from 0°C
±0.15% from 400°C
±0.15% from 500°C
±0.15% from 500°C
±0.1%
Shortest span Type L, J, U, T, K, E, N, chromel-copel:
Type S, R, B, D, C: 100°C
500°C
Range start/end freely programmable within the limits, in 0.1°C steps
Cold junction Pt100 internal or thermostat external constant
Cold junction accuracy (internal) ± 1°C
Cold junction temperature (external) -50 to +150°C, adjustable
Sampling cycle 3 or 6 channels, 250msec
Input filter 2nd order digital filter; filter constant adjustable from 0 to 10.0sec
Test voltage for electrical isolation 350V (via optocoupler)
Resolution >14 bit
Special features also programmable in °F
1
The accuracy refers to the maximum measuring range. The accuracy is reduced with short spans.
