Outputs (extra code)
Interfaces
Screen
Electrical data
Housing
Approvals/marks of conformity
3 relays
changeover (SPDT) (3A, 230V)
Setup interface (standard)
to read and write measurement, instrument, and configuration data (Modbus protocol)
RS232 / RS485 (extra code)
to read and write measurement, instrument, and configuration data (Modbus protocol)
Ethernet (extra code)
to read and write measurement, instrument and configuration data (Modbus-TCP protocol)
Resolution
320 x 240 pixels
Size
5“
Number of colors
27 colors
Screen refresh rate
≥
150Hz
Contrast setting
adjustable on instrument
Screen saver (switch-off)
through waiting time or control signal
Supply
(switch-mode PSU)
110 — 240 V AC +10/-15%, 48 — 63Hz or
20 — 53V AC/DC, 48 — 63Hz
Test voltages (type test)
- electrical supply to measuring circuit
- electrical supply to housing
(protective earth)
- measuring circuits to other
measuring circuits and housing
- electrical isolation between
the analog inputs
to EN 61 010, Part 1, March 1994
overvoltage category II, pollution degree 2
for supply voltage: AC 2.3kV/50Hz, 1min,
for supply voltage: AC/DC 510V/50Hz, 1min
for supply voltage: AC 2.3kV/50Hz, 1min,
for supply voltage: AC/DC 510V/50Hz, 1min
350V/50Hz, 1min
up to 30V AC and 50V DC
Supply voltage error
< 0.1% of range span
Power consumption
approx. 25VA
Data backup
see page 6
Electrical connection
At the back, via pluggable screw terminals,
conductor cross-section
≤
2.5mm
2
or 2 x 1.5mm
2
with core end ferrules.
Electromagnetic compatibility (EMC)
- interference emission
- interference immunity
EN 61 326-1
Class A - only for industrial use -
to industrial requirements
Safety regulations
to EN 61 010
Enclosure protection
to EN 60 529 category 2, front IP54, back IP20
Ambient temperature range
0 to +50°C
Ambient temperature error
0.03%/°C
Storage temperature range
-20 to +60°C
Housing type
- housing door
housing for flush panel mounting to IEC 61 554, galvanized steel sheet
zinc die-casting
Bezel size
144mm x 144mm
Depth behind panel
214mm, including connectors
Panel cut-out
138
+1.0
mm x 138
+1.0
mm
Panel thickness
2 — 40mm
Housing mounting
in panel to DIN 43 834
Climatic conditions
≤
75% relative humidity, no condensation
Operating position
unrestricted, but taking into account the viewing angle of the screen,
horizontally ±50°, vertically ±30°
Enclosure protection
to EN 60 529 Category 2,
IP54 front (IP65 with extra code 266), IP20 back
Weight
approx. 3.5kg
Mark of
conformity
Testing
laboratory
Certificates /
certification numbers
Test basis
valid for
c UL us
Underwriters
Laboratories
E 201387
UL 61010-1
CAN/CSA-C22.2 No. 61010-1
the flush-mounted instrument;
not in conjunction with extra
code 350
