background image

2 Identifying the instrument version

12

2.2 Order details

List extra codes in sequence, separated by commas.

(1)

Basic type

706585

LOGOSCREEN fd

(2)

Basic type extension

0

No software package

1

With software package (setup program, PCA3000, PCC, PCS, PCAT, USB cable)

(3)

Language / Setup

8

Factory setting (German/English)

9

Set to customer specification

(4)

Module slot 1

0

Not used

2

3 analog inputs and 8 binary inputs/outputs

3

6 analog inputs

(5)

Module slot 2

0

Not used

2

3 analog inputs and 8 binary inputs/outputs

3

6 analog inputs

(6)

Module slot 3

0

Not used

1

6 relay outputs

2

3 analog inputs and 8 binary inputs/outputs

3

6 analog inputs

(7)

Voltage supply

25

AC/DC 20 to 30 V, 48 to 63 Hz

33

AC 100 to 240 V +10/-15 %, 48 to 63 Hz

(8)

Extra codes memory

020

Lithium battery for memory buffering (ex-factory)

021

Storage capacitor

(9)

Extra codes

.

Not used

260

Math and logic module

(10)

Extra codes housing

.

Not used

350

Universal carrying case TG-35

a

444

Stainless steel front with touchpad

(11)

Extra codes

.

Without extra codes

267

PROFIBUS-DP interface

a

This extra code is available in combination with voltage supply AC 100 to 240 V, not with low supply voltage.
UL and ATEX approvals not applicable. The protection type in the carrying case corresponds to IP20, out-
side IP20D.

Order code

(1)

(2)

(3)

(4)

(5)

(6)

(7)

(8)

(9)

(10)

(11)

Order example

706585

/

-

-

/

,

,

,
