Transducer short circuit/break
Binary inputs/outputs (option)
Outputs
Interfaces
Input filter
2nd order digital filter; filter constant adjustable from 0 to 10.0 sec
Electrical isolation
see “Electrical data” on page 5 and
“Overview of the electrical isolation” on page 18
Resolution
>14 bit
a
The linearization accuracy refers to the maximum measuring range. The linearization accuracy is reduced with short spans.
Short-circuit
a
a
Programmable reaction of device, e.g. triggering alarm
Break
a
Thermocouple
not detected
detected
Resistance thermometer
detected
detected
Resistance transmitter
not detected
detected
Potentiometer
not detected
detected
Voltage
±210 mV
not detected
detected
Voltage > ±210 mV
not detected
not detected
Current
not detected
not detected
Input or output
configurable as input or output
Number
8, 16 or 24, depending on the device version,
to DIN VDE 0411, Part 500; max. 25 Hz, max. 32 V
Input
•
level
logic "0": -3 to +5 V (input current max. ±1 mA),
logic "1": 12 to 30 V (2.5 mA
input current 5 mA)
•
counting frequency
8Hz
High-speed input
the first two binary inputs of each module (B1, B2, B9, B10, B17, B18),
if the module is not fitted with relays or 6 analog inputs
•
task
count function, e.g. for flow measurement
•
counting frequency
10 kHz
Output
•
type
open-collector output, switches relative to positive voltage
•
level
logic "0": transistor is inhibited
(max. permissible voltage across switching transistor 30 V, max. leakage current 0.1 mA)
logic "1": transistor is switched on
(max. voltage across switching transistor 1.6 V, max. current 50 mA)
•
sampling cycle
at least 1 sec (1 Hz)
1 relay (ex-factory)
changeover (SPDT), 3 A, 230 V AC
a
a
With resistive load.
6 relays (option)
changeover (SPDT), 3 A, 230 V AC
a, b
b
It is not permissible to mix SELV circuits and supply circuits.
RS232/RS485 (connector 7)
Qty. 1, switchable between RS232 and RS485
•
protocol
Modbus master, Modbus slave and barcode reader
•
baud rate
9600, 19200, 38400
•
modem
can be connected
•
connector
SUB-D
•
external inputs
via the Modbus master/slave function, 24 analog and 24 binary
Basic range
Accuracy
a
Input resistance
