JUMO PCA3000 PC Evaluation Software - Manual (Page 43)

43
9 Evaluation - Table area
Select data
views All changes are instantly shown in the current table area. Switching registers
into and out of display will only become permanently effective when you click
.
h Press the left mouse button when the mouse pointer is positioned on a
register name, in order to switch the register into/out of display, or activate
one of the buttons that are available.
H
The submenu “Select data views” will also appear if you double-
click (left mouse button) a register name, e. g. .
Show all registers
Show standard register
Do not show register
Show/hide specific columns of a
selected register
Show all columns of all active registers
Show standard columns of all active registers
(standard columns are defined through PCA3000)
Se
le
cted r
e
gister
