37
8 Evaluation - Graphics area
Full-text search with regular expressions
The active ““Full-text search with regular expressions” is also AND-linked with
the individual batch search fields.
Use the button in order to enter wildcards, or have them explained.
Batch info This function shows the batch texts for the displayed batch. It only becomes
available when the data of a specific batch have come into display by using
the function Search for batch.
Zoom forwards
(zoom in) Zoom forwards is used to restore the next zoom display. This function is only
available if Zoom backwards has been used previously. As an alternative to the
mouse, Zoom forwards can also be executed from the PC keyboard (page up).
Zoom
backwards
(zoom out) Zoom backwards is used to restore the last zoom display. This function is only
available if zooming has been carried out. As an alternative to the mouse,
Zoom backwards can also be executed from the PC keyboard (page down).
Supplementary
description The “Supplementary description” function is described on page 79.
Reset zoom Reset zoom will restore the display of the entire time period for the selected
evaluation. As an alternative to the mouse, Reset zoom can also be executed
from the PC keyboard (Home).
Sign time
period This function can be used to sign the current contents of the graphics area.
After calling up the function Sign time period, a submenu will appear in which
you will be asked for the designation. The designation is defined in the device
through the parameter Configuration
! El. Signature ! Designation !
Significance and through the parameter Configuration ! El. Signature !
Designation ! El. signature. When the designation has been selected, signing
takes place by selecting the user ID and password.
Wildcards
H
If you want to use the PC keyboard for zooming, the graphics area
must be the active window. If the table area is to be the active
window, you will have to click on the graphics first.
