5 Operation

5.2.2

System states and errors

The following table lists all the system states and errors that are indicated by the "S" LED (Sta-
tus). In most cases, further diagnostics must be performed with the setup program.

Category

"S" LED
(Status)

Meaning

Diagnos-
tics with

Recommended action

Bus status

No connection to central processing
unit

LED

Check whether the central pro-
cessing unit is running; check
cabling and topology

Bus status

System in "Stop" (INIT) state – no
error, only in start phase

LED

Bus status

System in "Stop" (PREOP) state – no
error, only in start phase

LED

Operation

(Priority 3)

System in "Stop" (SAFEOP) state –
no error

LED

Operation

(Priority 3)

System in "Run" (OP) state – no
error

LED
