13
2 Description
2.1 Brief description
The module is equipped with 12 channels which can optionally be configured as digital inputs
or digital outputs.
The digitized input states are available in the system for further processing. The digital outputs
are actuated via the system bus by digital signals (assignment via the connection list or directly
by the PLC).
The load current of up to 6 A (12 × max. 500 mA) must be provided via the terminals +24V/
GND at the front.
LEDs are used to indicate applied voltage supply, the module operating status, as well as the
digital input/output status.
A setup program can be used to comfortably configure the digital input/output module.
For service work, the module insert can be easily pulled out of the case at the front. The case
including the bus PCB remains mounted on the DIN rail.
2.2 Block diagram
12 Digitalein- oder -ausgänge
(DC 0/24 V) frei konfigurierbar
705030
Spannungsversorgung Systembus
Externe
Spannungsversorgung
für digitale Ein-/Ausgänge
