Recirculating Cooler
11
Eco- Series
Temperature selection digital
via keypad indication on LED-Multi-Display
remote control via personal computer indication on monitor
Temperature indication °C LED-Multi-Display
Resolution °C 0.1
Electrical connection:
Computer interface RS232
Table 1
Pump capacity
Bath fluid: Water, Silicone -oil
XX.XX
PUMP
1
XX.XX
PUMP
2
Circulating pump:
P3 P3
Flow rate max. Lpm at 0 bar
30 33
Pressure max. bar at 0 liter
1.8 3.5
Bath fluid: Galden ®
eg. Fluorinert ® 3283
Pressure max. bar at 0 liter
3.5
Notice:
If Galden ® or Fluorinert ® is used the charge of the motor increases. Wrong
adjustment causes overheating and eventually destruction of the motor.
 With the circulation pump P3 a maximum pump pressure stage >PUMP 1< may
be adjusted.
The pump type can be recognized in the order no. on the name plate.
95 xx xxx _ xx PX xx
