DIGI-44B Installation Guide
Output 3 Commands
Function Command Response
Select Input 1 cir 5E s30 The updated status for output 3. Represented as an ASCII
string in the format of “sXY” where:
• X is the output channel
• The value of Y maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
Select Input 2 cir 06 s31
Select Input 3 cir 05 s32
Select Input 4 cir 03 s33
Select Input Up cir 48 new route
Select Input Down cir 55 new route
Output 4 Commands
Function Command Response
Select Input 1 cir 18 s40 The updated status for output 4. Represented as an ASCII
string in the format of “sXY” where:
• X is the output channel
• The value of Y maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
Select Input 2 cir 44 s41
Select Input 3 cir 0F s42
Select Input 4 cir 51 s43
Select Input Up cir 40 new route
Select Input Down cir 07 new route
RS232 & TCP/IP System Commands
Misc. Commands
Function Command Response
Get Device Type br aDIGI-44B ASCII string containing the letter
“a” followed by the name of the
device
Get Device Status bc Ex:
s10
s21
s32
s43
ASCII string in the format of:
“s1Ys2Ys3Ys4Y” where Y is the
input source being routed to each
output. Each segment is
separated by a .
The value of Y maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
The output channels map as
follows:
s1 = output 1
s2 = output 2
s3 = output 3
s4 = output 4
Get IP Mode and
Address
gipm Static IP Ex:
ipm sip 192 168 001 114
ASCII string containing
“ipm” followed by IP
mode, the IP address,
The value of the IP mode map as
follows:
sip = Static IP Mode
dhc = Dynamic IP Mode
DHCP IP Ex:
ipm dhc 192 168 001 101
