SKYPLAY-MX Installation Guide
14
Multiple Transmitters on a Receiver
(Many-To-Point)
To pair additional transmitter to a receiver:
1. Mount the transmitter and the receiver in the
desktop stand for proper ventilation. (See Shelf
Mounting Instructions)
2. Connect an HDMI cable from the HD Source to the
SKYPLAY-MX-S transmitter.
3. Connect an HDMI cable from the SKYPLAY-MX-R
receiver to the HD display.
4. Power down other SKYPLAY-MX devices for ease of
installation.
5. Power on both the transmitter and receiver to be
paired.
6. Point the IR remote at the SKYPLAY-MX-R receiver
and Press the “Add” button.
7. The On-Screen Display shows “Please Activate the
Registration on Transmitter Unit”.
8. Use a paperclip to Press and Hold the Pairing Button
on the front of the SKYPLAY-MX-S transmitter unit
the Network LED begins to blink.
9. Wait for the On-Screen Display to display the
“Adding …” message.
10. Press the “OK” button on the IR Remote to confirm
the addition of the receiver.
11. Wait for the pairing to complete, screen may flash
during pairing this is normal.
12. Setup is complete.
