SKYPLAY-MX Installation Guide
13
Point-to-Many
The SKYPLAY-MX-S supports the ability to connect up to
4 receivers at a time. In order to setup point-to-many
installations it is easiest to pair one receiver to the
transmitter at a time.
1. Mount the transmitter and all of the receivers in
their desktop stand for proper ventilation. (See Shelf
Mounting Instructions)
2. Connect an HDMI cable from the HD Source to the
SKYPLAY-MX-S transmitter.
3. Connect HDMI cables from the SKYPLAY-MX-R
receivers to their respective HD displays.
4. Power on the transmitter.
5. Power on only one receiver at a time for ease of
installation.
6. Point the IR remote at the SKYPLAY-MX-R receiver
and Press the “Add” button.
7. The On-Screen Display shows “Please Activate the
Registration on Transmitter Unit”.
8. Use a paperclip to Press and Hold the Pairing Button
on the front of the SKYPLAY-MX-S transmitter unit
the Network LED begins to blink.
9. Wait for the On-Screen Display to display the
“Adding …” message.
10. Press the “OK” button on the IR Remote to confirm
the addition of the receiver.
11. Wait for the pairing to complete, screen may flash
during pairing this is normal.
12. In order to pair additional receivers to the
transmitter, Power down the SKYPLAY-MX-R
receiver.
13. Repeat steps 5 through 12 for each receiver.
14. Once all receivers have been paired to the
transmitter power on all the receivers.
15. Setup is complete.
