INFICON HPG400 ATM to High-Vacuum Gauge User Manual
Page 4
4
tina31e1 (2004-05) HPG400 v1.om
Contents
Product Identification
2
Validity
2
Intended Use
3
Functional Principle
3
Trademarks
3
1 Safety
6
1.1 Symbols Used
6
1.2 Personnel Qualifications
6
1.3 General Safety Instructions
7
1.4 Liability and Warranty
7
2 Technical Data
8
3 Installation
13
3.1 Vacuum Connection
13
3.1.1
Removing and Installing the Electronics Unit
15
3.2 Electrical Connection
16
3.2.1
Use With INFICON VGC4XX Vacuum Gauge Controller
16
3.2.2
Use With Other Controllers
17
3.2.2.1
Making a Sensor Cable
17
3.2.2.2
Making a DeviceNet Interface Cable (HPG400-SD)
19
3.2.2.3
Making a Profibus Interface Cable (HPG400-SP)
20
3.2.3
Using the Optional Power Supply (With RS232C Line)
21
4 Operation
23
4.1 Measuring Principle, Measuring Behavior
23
4.2 Operational Principle of the Gauge
25
4.3 Putting the Gauge Into Operation
26
4.4 Display (HPG400)
27
4.5 RS232C Interface
28
4.5.1
Description of the Functions
28
4.5.1.1
Output String (Transmit)
28
4.5.1.2
Input String (Receive)
30
4.6 DeviceNet Interface (HPG400-SD)
31
4.6.1
Description of the Functions
31
4.6.2
Operating Parameters
31
4.6.2.1
Operating Software
31
4.6.2.2
Node Address Setting
31
4.6.2.3
Data Rate Setting
32
4.6.3
Status Lights
32
4.7 Profibus Interface (HPG400-SP)
33
4.7.1
Description of the Functions
33
4.7.2
Operating Parameters
33
4.7.2.1
Operating Software
33
4.7.2.2
Node Address Setting
33
4.8 Switching Functions (HPG400-SD, HPG400-SP)
34
4.8.1
Setting the Switching Functions
34
5 Deinstallation
36
