In all communications with INFICON, please specify the information on the product
nameplate. For convenient reference copy that information into the space provided
below.
Typ:
No:
F-No:
V W
INFICON AG, LI-9496 Balzers
This document applies to products with the following part numbers:
HPG400 ( without display)
353-520 (vacuum connection DN 25 ISO-KF)
353-522 (vacuum connection DN 40 CF-R)
HPG400 (with display)
353-521 (vacuum connection DN 25 ISO-KF)
353-523 (vacuum connection DN 40 CF-R)
HPG400-SD (with DeviceNet interface and switching functions)
353-527 (vacuum connection DN 25 ISO-KF)
353-528 (vacuum connection DN 40 CF-R)
HPG400-SP (with Profibus interface and switching functions)
353-525 (vacuum connection DN 25 ISO-KF)
353-526 (vacuum connection DN 40 CF-R)
The part number (PN) can be taken from the product nameplate.
If not indicated otherwise in the legends, the illustrations in this docu-
ment correspond to gauge with part number 353-520. They apply to the
other gauges by analogy.
All HPG400 versions are shipped with an instruction sheet (
→ [8]).
HPG400-SD and HPG400-SP come with a supplementary instruction sheet de-
scribing the fieldbus interfaces and the switching functions (
→ [9]).
We reserve the right to make technical changes without prior notice.
