tira68e1 (2013-05) CDGxxxD.cp
27
Index SI DataType NV Access PM Name
F940 0x01 UDINT RO Measurement Principle
0x02 BYTE RO Number of Sensors
0x04 V_STRING x RO SW Version VPG PCB
F9F0 V_STRING RO Manufacturer Serial
Number
F9F1 0x01 UDINT RO CDP Functional
Generation Number
Module 1
0x02 RO CDP Functional
Generation Number
Module 2
F9F2 0x01 UDINT RO SDP Functional
Generation Number
Module 1
0x02 UDINT RO SDP Functional
Generation Number
Module 2
F9F3 V_STRING RO Vendor Name
F9F4 0x01 V_STRING RO Semiconductor SDP
Device Name Module 1
0x02 V_STRING RO Semiconductor SDP
Device Name Module 2
F9F5 0x01 USINT RW Data stamp Module 1
0x02 USINT RW Data stamp Module 2
F9F6 UDINT RO Time since power on
F9F7 UDINT x RO Total time powered
F9F8 0x01 UDINT RO Firmware Update
Functional Generation
Number Module 1
F9F8 0x02 UDINT RO Firmware Update
Functional Generation
Number Module 2
Measurement principle assigned to the object instance.
The most significant nibble of the parameter represents the sensor type of the first
Module, the second most significant nibble of the parameter represents the sensor
type of the second Module, and so forth.
Measurement Principle (Index F940)
1
2
3
4
5 Capacitance Manometer
Piezo
Heat Transfer
Cold Cathode
Hot Cathode
Number of Sensors (Index F940): The number of sensors implemented on the
device.
4.7.14 Information Device
Subindex 0x01 (F940)
Subindex 0x02 (F940)
