Index SI DataType NV Access PM Name
9001 0x01 UINT RO Sensor Warning
0x02 UINT RO Sensor Alarm
Sensor Warnings
Bit 0
Bit 1…8
Bit 9
Bit 10…13
Bit 14
Bit 15
Not at temperature
0
Electronics Warning
0
Low Warning Exception
High Warning Exception
Sensor Alarms
Bit 0…8
Bit 9
Bit 10…13
Bit 14
Bit 15
0
Electronics Failure
0
Low Alarm Exception
High Alarm Exception
Index SI DataType NV Access PM Name
9010 0x01 REAL x RO Accumulated Zero Offset
0x02 REAL x RO Highest Informational
Measurement Value
0x03 REAL x RO Highest Precision
Measurement Value
0x04 REAL x RO Lowest Precision
Measurement Value
Accumulated Zero Offset: An amount added prior to Gain to derive Value. Result of
Zero Adjust Command (accumulated value).
Highest Informational Measurement Value: Highest value that the gauge can
measure without a specified accuracy.
Highest Precision Measurement Value: Highest valid value at which the gauge is
specified with an accuracy value. Above that value, the parameter Reading Valid is
set to invalid.
Lowest Precision Measurement Value: Lowest valid value at which the gauge is
specified with an accuracy value. Below that value, the parameter Reading Valid is
set to invalid.
Index SI DataType NV Access PM Name
9012 0x01 UINT RO Sensor Warning
0x02 UINT RO Sensor Alarm
Sensor Warnings
Bit 0…15
0
Sensor Alarms
Bit 0…15
0
4.6.1 Information
Capacitance Diaphragm
Subindex 0x01
Subindex 0x02
4.6.2 Information Common
Subindex 0x01
Subindex 0x02
Subindex 0x03
Subindex 0x04
4.6.3 Information Piezo
Subindex 0x01
Subindex 0x02
