INFICON PCG55x ATM to Medium Vacuum Gauge User Manual
Page 52
52
tina56e1-d (2014-01)
LED Meaning
off No
supply
blinking green-red
Selftest
lit solid green
Normal operation
lit solid red
Non recoverable error
blinking red
Recoverable error (e.g. missing
DeviceNet power supply)
LED Meaning
off
Gauge not online:
• Selftest not yet concluded
• No supply, → "STATUS MOD"
blinking green
Gauge online but no communication:
• Selftest concluded but no communica-
tion to other nodes established
• Gauge not assigned to any master
lit solid green
Gauge online; necessary connections
established
blinking red
One or several input / output connections in
"time out" status
lit solid red
Communication error. The gauge has de-
tected an error that impedes communica-
tion via the network (e.g. two identical node
addresses (MAC IC) or "Bus-off")
