Validity
This document applies to products of the PCG55x series.
Part numbers of standard products are indicated below. OEM
products have other part numbers and different parameter
settings (e.g. factory setting of setpoint) as defined in the
corresponding ordering information.
3PCx-0xx-xxxx
Flange 1  DN 16 ISO-KF
2  DN 16 ISO-KF long tube
4  DN 16 CF-F
5  DN 16 CF-R long tube
6
 DN 25 ISO-KF
D  4 VCR female
E
 8 VCR female
F  1/8" NPT
K  Flange 29×29 mm
M  4 VCR 90° female
N  7/16-20 UNF male
0  mbar
1  Torr
2  Pa
3  micron
Unit
1  Tungsten
2  Nickel
3  Ceramic coated
6  Tungsten, galvanically isolated
7  Nickel, galvanically isolated
8  Ceramic coated,
galvanically isolated
Filament
